Oven Universal Digital
APPLICATIONS OF OVEN UNIVERSAL DIGITAL
- Double Walled Oven Universal (Memmert Type) is elegantly designed in various applications for microbiology, cell cultivation of animals and plants, food studies; general heating, drying, sterilizing, baking, to perform: material tests, ageing of computer chips, run complex experiments with highly sensitive loads, drying or tempering electronic components, hardening plastic resin. Our U universal oven stands for unparalleled precise, even and gentle temperature control.
- Double Walled Oven Universal (Memmert Type) is low cost options for heating- for various experiments in, industries, R&D labs, Pharmaceutical, Food & Beverage Industries and Institutions- in the field of Medical, Agricultural and Industrial Research.
SALIENT FEATURES & CONSTRUCTION OF OVEN UNIVERSAL DIGITAL
- Outer chamber is made of Mild Steel duly powder coated.
- Inner chamber made of ALUMINIUM or STAINLESS STEEL (304) sheet.
- Forced convection system by motor & blowers fitted ensures good mixing, strong dispersion and maintains higher temperature uniformity inside the chamber & no cross contamination.
- Thermal loss is prevented by filling mineral wool (Insulation) in space between the outer body & Inner chamber.
- Door Gasket fixed on the double walled door for proper sealing.
- Fitted with heavy hinges with a ball catcher, spring loaded door closing device. Door is duly insulated.
- Adjustable two ventilation slides control inner air / vapour circulation.
- Beaded heating elements made of high quality Nichrome/Kanthal wire are placed in ribs, at bottom and sides for uniform heat distribution.
- Inner chamber has ribs for placing the shelves at convenient levels. Supplied with 2 or 3 removable shelves.
- Temperature is controlled by electronic digital temperature indicator cum controller from 50°C to 250°C ± 1°C. fitted on the front panel for easy operations.
- Different programme functions can be designed for a wide variety of applications, and even when used
- Temperature is displayed by Digital LED with SV and PV display at front of the oven.
- Front Panel is provided with ON/OFF switch, temperature controller and indicators
- Supplied with cord and plug.
- Operating Voltage: 220 Volts AC (50 Hz).
TECHNICAL SPECIFICATIONS & ORDERING INFORMATION OF OVEN UNIVERSAL DIGITAL
| Model No. | RI-183 (A)(A) | RI-183 (A)(B) | RI-183 (A)(C) | RI-183 (A)(D) | RI-183 (A)(E) | RI-183 (A)(F) | RI-183 (A)(G) | RI-183(A) (H) | |
| Inner Chamber in MM (W x H x D) | 300x300x300 | 355x355x355 | 455x455x455 | 455x455x605 | 455 x 605 x 605 | 605x605x605 | 605x455x910 | 605x910x605 | |
| Inches Conversion | 12 x 12 x 12 | 14 x 14 x 14 | 18 x 18 x 18 | 18 x 18 x 24 | 18 x 24 x 24 | 24 x 24 x 24 | 24 x 18 x 36 | 24 x 24 x 36 | |
| Capacity | 28 ltrs | 43 ltrs | 90 ltrs | 105 ltrs | 120 ltr | 215 ltrs | 240 ltrs | 325 ltrs | |
| Heating Load | 1.0 0 KW | 1.00 KW | 1.50 KW | 1.50 KW | 2.00 KW | 2. 50 KW | 2.50 KW | 3.00 KW | |
| No. of Shelves | 2 | 2 | 2 | 2 | 2 | 2 | 3 | 3 | |
| Temperature Range | 50°C to 250°C | ||||||||
| Temp. Controller | By Microprocessor Based PID Digital Temperature Indicator cum Controller. | ||||||||
| Temp. Sensitivity | +1°C. | ||||||||
| Air Circulation | By forced convection system | ||||||||
| Relay | Solid state electronic relay with protective heat sink. | ||||||||
| Auto Tuning System | System is compatible with auto tuning system | ||||||||
