APPLICATIONS OF OVEN UNIVERSAL

• Double Walled Oven Universal (Memmert Type) is elegantly designed in various applications for microbiology, cell cultivation of animals and plants, food studies; general heating, drying, sterilizing, baking, to perform: material tests, ageing of computer chips, run complex experiments with highly sensitive loads, drying or tempering electronic components, hardening plastic resin. Our U universal oven stands for unparalleled precise, even and gentle temperature control.
• Double Walled Oven Universal (Memmert Type) is low-cost options for heating- for various experiments in, industries, R&D labs, Pharmaceutical, Food & Beverage Industries and Institutions- in the field of Medical, Agricultural and Industrial Research.

SALIENT FEATURES & CONSTRUCTION OF OVEN UNIVERSAL

• Outer chamber is made of Mild Steel duly powder coated.
• Inner chamber made of ALUMINIUM or STAINLESS STEEL sheet.
• Forced convection system ensures good mixing, strong dispersion and maintains higher temperature uniformity inside the chamber.
• Thermal loss is prevented by filling mineral wool (Insulation) in space between the outer body & Inner chamber.
• Door Gasket fixed on the double walled door for proper sealing.
• Fitted with heavy hinges with a ball catcher, spring loaded door closing device. Door is duly insulated.
• Adjustable two ventilation slides control inner air / vapour circulation.
• Beaded heating elements made of high quality Nichrome/Kanthal wire are placed in ribs, at bottom and sides for uniform heat distribution.
• Inner chamber has ribs for placing the shelves at convenient levels. Supplied with 2 or 3 removable shelves.
• Temperature is controlled by capillary type thermostat from 50°C to 250°C ± 1°C. Temperature control knob is graduated in centigrade degrees
• Temperature is displayed on 'L' shape thermometer fixed at front of the oven.
• Front Panel is provided with ON/OFF switch, thermostat control knob and indicators for mains and thermostats. Supplied with cord and plug.
• Operating Voltage: 220 Volts AC (50 Hz).
• TECHNICAL SPECIFICATIONS & ORDERING INFORMATION OF OVEN UNIVERSAL
•

•
• OPTIONAL FEATURES OF OVEN UNIVERSAL
•
