APPLICATIONS brings the ultra-high-tech Triple walled Microprocessor controlled, solid-state heating/ cooling incubator (BOD Incubator ) down to earth.

• BOD Incubator is specially designed for incubation of Biochemical Oxygen demand on water and sewage; can be used as environmental study and growth chamber by incorporating lighting and humidification system.
• BOD Incubator is Used in various applications for microbiology, cell cultivation of animals, plants & food studies- where experiments requiring low temperature conditions. Used for microorganism or activation, good storage and desalting process of enzyme extracts and for preservation of vaccines, insulin, level extracts, a* 15°C for serological and complement fixation tests for enzymatic digestion process.

SALIENT FEATURES & CONSTRUCTION

• Robust construction outer chamber is made of Mild Steel duly pretreated& finished with powder coated paint for lasting finish.
• Inner chamber made of STAINLESS-STEEL SHEET (304 Grade).
• Fitted with durable coaxial blower for forced air circulation at triple walled back to maintain temperature uniformity in the chamber.
• Outer front double walled door is insulated and is fitted with magnetic tape for air tight closing for no temperature loss, provided with lock and key arrangement.
• Door operated illumination lamp is fitted inside the chamber for easy visibility.
• A full view inner plexi-glass door enables inspection and monitoring of inner chamber specimens without disturbing the process temperature.
• High grade PUF INSULATION between outer and inner chamber for minimal thermal losses.
• Cooling is done by finned tube evaporator lie in the air circulation path by ISI marked Compressor/Condensing Units CFC free & R-134 a eco friendly refrigerant.
• Heating elements are placed in the path of moving air duly insulated from the body.
• Inner chamber has ribs for placing the shelves at convenient levels. Supplied with 2 or 3 removable shelves.
• Control panel having all controls and circuitry are housed at the top fitted with Temperature controller cum Indicator Microprocessor based with LED display for Set Value (SV) & Process Value (PV) to select any desired temperature provided with Volt meter on the panel to read the incoming voltage.
• Caster wheel mounted for easy portability.
• BOD Incubator is supplied with cord and plug.
• Operating Voltage: 220 Volts AC (50 Hz).
• TECHNICAL SPECIFICATIONS & ORDERING INFORMATION
•
